ORTF Surround Indoor Set

Plug-and-Play set

Product is discontinued and no longer available.
Alternative: IRT-Cross Set

Features

  • indoor plug and play solution for surround smbience
  • optimal imaging characteristics like those of the “IRT Cross”: good 360° imaging with a pleasant, natural-sounding spatial impression
  • complete set including the mounting bar, four CCM 41 L supercardioids and the breakout cable
  • applications: sporting events, film sound, etc.

Order number

  • No. 123801

Description

The “ORTF Surround” recording method is a new system for the pickup of surround ambience. This microphone arrangement and its sonic characteristics are quite similar to those of the well-known “IRT Cross“ designed by Günther Theile. Both the 360° imaging and the spatial impression are of optimal quality. This is achieved with a high degree of signal separation among channels, based both on arrival-time differences and level differences.

The ORTF Surround Indoor Set comprises:

  • 4 * No: 121017: CCM 41 L, supercardioid compact microphones
  • No....

The “ORTF Surround” recording method is a new system for the pickup of surround ambience. This microphone arrangement and its sonic characteristics are quite similar to those of the well-known “IRT Cross“ designed by Günther Theile. Both the 360° imaging and the spatial impression are of optimal quality. This is achieved with a high degree of signal separation among channels, based both on arrival-time differences and level differences.

The ORTF Surround Indoor Set comprises:

  • 4 * No: 121017: CCM 41 L, supercardioid compact microphones
  • No. 154003: ORTF Surround Bar LM: a four-way “ORTF Surround Bar“ terminated with a Surround multi-pin connector (AES-65)
  • No. RYC-041107: Rycote Invision INV-7: an elastic suspension
  • No: 152407: K Surround 5 M: a 5-meter, four-way Binder multi-core cable
  • No. 152403: AK Surround M/4U: an adapter cable (Multipin / 4 × XLR-3M)

When working indoors, the ORTF Surround Indoor Set is used without windscreen. If a moderate degree of wind protection should be required, a B 5 D foam windscreen can be placed over each microphone separately.

moreless

Technical Specifications

Stereophonic recording technique

ORTF Surround / IRT Cross
